Product detail:
Dongfeng concrete truck
Dongfeng 6CBM concrete mixer truck
| Technique parameter | |||
| Name | Dongfeng 6m³ concrete mixer truck | L×W×H mm | 8000×2500×3700(mm) |
| Chassis Model | EQ3120GSZ3GJ | Cargo body Dimension(mm) | ××(mm) |
| total mass | 12000(Kg) | Approach/Departure angle | 25/23(°) |
| Rated mass | 4680(Kg) | front/rear suspension | 1250/2250(mm) |
| curb mass | 7125(Kg) | Max. speed | 85(km/h) |
| Engine | manufacturer | displacement(ml) | power(kw) |
| YC6J190-33 YC6J170-33 B190 33 B170 33 ISDe185 30 YC6J190-30 | Guangxi Yuchai Machinery Co., Ltd. Dongfeng Cummins Engine Co., Ltd. | 6494 6494 5900 5900 6700 6500 | 140 125 140 125 136 140 |
| Emission standards | GB3847-2005,GB17691-2005Euro3 | ||
| Axle | 2 | front tread | 1940/1860(mm) |
| wheelbase | 4200,4500mm | ar tread | 1860(mm) |
| tyre | 6 | tyre size | 10.00-20,10.00R20 |
| fuel type | diesel | spring | 8/10+7 |
| axle load | 4000/8000kg | cab passenger | 3 |
| Note | mixing tank capacity:6 cubic meters | ||
| Special performance | Mixing tank: the structure is an ordinary pear shape. Mixing water which is supplied during the transporting process is injected into tank from the head of mixing tank. Transmission system: the drive method of mixing tank is taking engine as power source, and takes power from PTO on the rear part of engine. The power is transmit through transmission shaft to variable plunger pump and mixing tank rotates through speed reducer. Feeding and charging system of mixing tank: important device which can help mixing tank work. Operation system: control unit of the truck. There is “H” shape groove on control panel, which is moving space of control stick; there is spacing hole on rear part of groove, which is used for fixing the position of control stick. There is a left control stick and a right control stick on the tail part of truck, which are used to control mixing tank’s prograde, invert and speed. Water supply system: mainly use for cleaning mixing system. | ||
The main products are
1. Water truck
2. Fuel tanker truck, Oil Truck, Tanker Truck
3.Fire engine truck
4.Truck mounted with crane
5.Dump truck,tipper,heavy duty truck
6.LPG Tank Truck, LPG Truck, LPG Tanker, LPG Semi-trailer, LPG Storage Tanker
6. Bulk cement truck
7. Concrete mixer truck, mixer truck, cement mixer truck
8. Garbage truck, Self-loading garbage truck,garbage compactor truck,sealed garbage truck
9.Fecal suction truck,sewage suction truck
10. High altitude working truck
11. Chemical liquid truck
12. Van truck,insulated truck,refrigeration truck
13. Semi Trailer, Low plate semi-trailer,oil semi-trailer,van semi-trailer,bulk cement transportation semi-trailer,container semi-trailer,chemical liquid semitrailer,etc more than 300 types in total.
Contact with lisa for more information and price!
