Specification( 1×10mm2)

Type

TUV 2 PFG 1169 1×10mm2

Conductor

Material

Stranded tinned copper

Composition(NO./mm)

142/0.30

Insulation

Material

XLPE

Nominal Thickness(mm)

0.90

Sheath

Material

XLPE

Nominal Thickness(mm)

0.90

Outer Diameter(mm)

9.00±0.2

standard

TUV 2Pfg 1169 08.07

Rated voltage

AC Uo/U0.6~1.0KV , DC1.8KV

Ambient temperature

-40~+90°C

The expected period of use

25years

Flame rated

IEC60332-1-2

Conductor dc resistance

≤1.95Ω/km
