CMA3 G8J 40A automotive relay
1 Relay feature:
-40A switching capability
-1 form A.1form B .1formC.2 form Acontact arrangement
-Various mounting terminations available
-Sealed IP67 and dust cover tyoes available
-Outline dimensions :28.0*28.0*25.0mm
2.Specification:
CMA3 G8J 40A automotive relay
| characteristics | ||||||
| Contact Form | 1A 1B 1C 2A | |||||
| Contact material | Silver Alloy | |||||
| Max.Switching Current | NO/NC:120A/45A | |||||
| Max.Switching voltage | 75VDC | |||||
| Min.Contact Load | 1A 6VDC | |||||
| Electrical life | 100000 ops | |||||
| Mechanical Life | 10000000 ops | |||||
| Initial insulation resistance | 500MΩ | |||||
| Dielectric strength | 500VAC | |||||
| Operate Time | 7ms | |||||
| Release Time | 5ms | |||||
| Ambient temperature | -40°C~+85°C | |||||
| Astorage Temperature | -40°C~+155°C | |||||
| Termination | PCB,QC | |||||
| Construction | Sealed ,dust type | |||||
| Unit Weight | 34g | |||||
3.Relay Photo:
4.Drawing:
5.Package:
-50pcs/tray
-500pcs/carton
6.Applications
- fog light,head light,battery control,oil pumb control,fan control,air conditioner,harness -
