40M Range,IP67,ICR Varifocal,P2P/CMS/DDNS/WDR/POE/ONVIF door bell ip camera
| Model | GR-NW2430E | GR-NW2430L | GR-NW4430W | GR-NW6430L | |
| General | Feature | Lite version | Low Illumination | WDR | Low Illumination |
| Imaging sensor | 1/3" Aptina CMOS | 1/2.5" Aptina CMOS | |||
| Pixels | 1.3 Megapixel | 3 Megapixel | 5 Megapixel | ||
| HD Output | 960P:1280×960 | 1080P:2048×1536 | 1080P:2560×1920 | ||
| Image Adjustable | 720P:1280×720 | 720P:1280×720 | 720P:1280×720 | ||
| D1:640×480 | D1:640×480 | D1:640×480 | |||
| Illumination | Color: 0.1Lux BW:0.01Lux(F1.2,AGC ON) | Color:0.6Lux BW:0.08Lux(F1.2,AGC ON) | |||
| IR Distance | 40m (42pcs black IR LED) | ||||
| Shutter Speed | 1/60~ 1/100,000S, Shutter speed Adjustable | ||||
| Lens | HD 4-9mm varifocal lens | ||||
| Exposure Control | DSP Auto Adjust | ||||
| AGC & W/B | Auto | ||||
| S/N Ratio | ≥50dB | ||||
| Network Function | Network Steadiness | Auto Reconnect, Register, UPNP, HB Display, Synchronization | |||
| Network Protocol | Support ONVIF 2.0, PPPOE,DHCP,TCP/IP,HTTP,UDP,RTP/RTCP, RTSP,UPNP, SMTP,FTP,NTP,DDNS,DNS etc. | ||||
| Dual Stream | Dual Stream Transfer (H.264,CBR/VBR Adjustable) | ||||
| Main Stream(1M~8Mbps) With Local Skim, SD Card etc. | |||||
| Sub-Stream(0.5MK~2Mbps) With Network Transfer, 3G Visit. | |||||
| Upgrade maintenance | Support Remote Upgrade, With Password Protect. | ||||
| Wireless | Without | Adapting WIFI or 3G, Adapting P2P Intelligence Mobile Phone Visit | |||
| Special Features | Optional Function | Without | Paid Options: P2P / POE / TF Card | ||
| bracket | 3-axis rotatable bracket (wire concealed) | ||||
| crust | Metal crust | ||||
| Waterproof rate | IP67 | ||||
| IR control | smart IR light control to avoid IR over Exposure | ||||
| Smart Alarm | Motion detect,Video Shelter,Video Lost, IP Address Conflict, Store Abnormal. | ||||
| Video Efficiency | Pixels/ frame rate | 1280×720P | 2048×1536P | 2560×1920P | |
| 50Hz/60Hz: 30fps/25fps | 50Hz/60Hz: 20fps/15fps | 50Hz/60Hz: 10fps | |||
| Image Capture | JPEG for local storage | ||||
| Image Setting | Saturation, Luminance, Contrast Ratio Adjustable Through Client software or IE. | ||||
| Image rolling-over | Level transposition, turn up-side down, easy for install & Adjust. | ||||
| Audio | Audio Encoding | Without | G.726/G.722/G.711 standard code, voice monitor, two-way audio speak | ||
| Audio Function | Without | Audio Broadcast, Audio talkback | |||
| Mount | Power Mount | DC female connector, 5.5×2.1mm | |||
| Network Mount | 1ch 10M/100M ether net mouth, RJ45 Mount | ||||
| Video Output | 1ch local analog output, BNC interface. | ||||
| Alarm Mount | Without | 1ch alarm input,1ch alarm output | |||
| Audio Mount | Without | 1ch audio input,1ch audio output | |||
| RS485 Mount | Without | 1ch RS485 | |||
| Others | Work Temperature | Circle temperature: -10°C~+60°C Body temperature: 25°C~35°C | |||
| Work humidity: <90% (without condensation) | |||||
| Power Consumption | DC 12V±5% , IR ON: 8W | ||||
| SIZE(mm) | Unit packing:285 × 176 × 138 mm Crton size:610 × 430 × 400 mm (14pcs/CTN) | ||||
| Weight(Kg) | Unit Weight: 1.65 Kg~1.75 Kg Carton Weight: 23.10 Kg~24.50 Kg | ||||
