Manufacturer of Electronic Weigh Bridge
U-shape beam, rational structure, save material, high strength and firmness, low platform, modular, sealed cavity, anticorrosion, convenient installation.
Technical parameters of weigh bridge:
1. Accuracy class: OIML III; dynamic: 0.5 - 0.2%
2. Environmental temperature:
weighing indicator: -10- +40°C; weighing platform : -30°C- +65°C
3. Environmental humidity: <90% RH, without dew .
4.Power supply: 220V(AC) 50Hz
| model | Scs-20 | Scs-30 | scs-50 | Scs-60 | Scs-80 | Scs-100 | Scs-120 | Scs-150 |
| Max weighing(T) | 20 | 30 | 50 | 60 | 80 | 100 | 120 | 150 |
| interval(kg) | 10 | 10 | 20 | 20 | 20 | 20 | 20 | 50 |
| 2.0×4 | Y | |||||||
| 3.0×7 | Y | Y | ||||||
| 3.0×9 | Y | |||||||
| 3.0×10 | Y | |||||||
| 3.0×12 | Y | Y | Y | |||||
| 3.0×14 | Y | Y | ||||||
| 3.0×15 | Y | Y | Y | Y | ||||
| 3.0×16 | Y | Y | Y | Y | Y | |||
| 3.0×18 | Y | Y | Y | Y | Y | |||
| 3.4×14 | Y | Y | Y | |||||
| 3.4×16 | Y | Y | Y | Y | Y | |||
| 3.4×18 | Y | Y | Y | Y | Y | |||
| 3.4×21 | Y | Y | Y | Y | Y |
PS: Our company accepts special specification order. Y represents optimal specifications.
