18.9ltr bottle blowing machine with high quality mold
Automatic bottle blow molding machine can produce PET containers including the baby feeding bottles infusion bottle according to the different bottle shape and diameter. It has automobile system with high efficiency. The distant infrared ray heat pipe are used in the machine ,It has high pressure protection with the feature of precisely removing mould ,The machine has no noise ,It is easy to maintain ,It's the equipment for producing PET bottles
High temperature Blow Molding Machine-specific warm-up through the perform . Preform cooling. Reheating preforms . Further cooling. Reciprocating cycle. The end, the preforms suitable for stretch blow roasted state. Bottle blowing uniform wall thickness. Transparent performance characteristics well. Mainly used in high-temperature filler. Temperature reached 90 degree. And it can withstand high temperature second sterilization.
18.9ltr bottle blowing machine with high quality mold
Technical parameters of bottle blowing machine: | |
Model | HY-Y |
Capacity | 80-90PCS/H |
Max.heating power | 14kw |
Pressure of air supply | 2.5MPa |
Max.dimension of mould | 20*35*38cm |
Max.shifting mould dimension | 17cm |
Center distance between two bottles | min9cm max20cm |
Max. stretched length | 35cm |
Weight | 650kg |
main machine size | 1600*600*1610mm |
Oven | 1870*630*1450mm |
High pressure air compressor: | |
Air compressor | 1.0M3/30KG |
Volume | 1.0M3 |
Pressure | 30kg |
Speed | 800r/min |
Power | 11KW |
Overall Dimension | 1790×530×1200mm |
Weight | 480KG |
18.9ltr bottle blowing machine with high quality mold
Features:
1) Stable performance with advanced PLC
2) Strong penetrability and good and swift distribution of the heat by letting
the bottles rotate by itself and revolute in the rails simultaneously in the
infrared preheater
3) High adjustability to enable the preheater to preheat performs in shapes by
adjusting the light tube and the length of the reflecting board in the
preheating area, and eternal temperature in the preheater with an automatic
thermostatic apparatus
4) High safeties with security automatic-locking apparatus in each mechanical
action, which will make the procedures turn into the state of safety in case
of a breakdown in certain procedure
5) No contamination and low noise with the air cylinder to drive the action
instead of the oil pump
6) Satisfaction with different atmospheric pressure for blowing and action by
dividing the blowing and action into three parts in the air pressure diagram
of the machine
7) Strong clamping force with high pressure and double crank links to lock the
mold
8) Two ways of operating: automatic and manual
9) Safe, reliable, and unique design of the position of valve to make the air
pressure diagram of the machine easier to understand
10) Low cost, high efficiency, easy operation, easy maintenance, etc, due to
automatic technological process
11) Ideal effect of the chilling with the chilling system
12) Easy installation and starting
13) Low rejection rate: less than 0.2 percent
18.9ltr bottle blowing machine with high quality mold
Product scope
| Drinking pure water plant | Nature mineral water plant | 3L water bottling plant | Doy-pack liquid filling plant |
| Bottle unscrambler | 5 Gallon water production line | 3 in 1 Bottle water filling machine | Pouch water filling packing machine |
18.9ltr bottle blowing machine with high quality mold
