Brand:aa
Product detail:
Full servo press brake power saving:
Full servo motors,energy efficient.
Low noise.
Welded structure to relive the internal stress and to avoid the deformation of the boday.
Propotional hydraulic compensation.
Electro-hydraulic servo synchronous module and pressure module.
Y'sxits full closed loop control.
Precise bachgague with double ball screw and three liner guide rails.
+/-0.01mm repeat accuracies.
Powerfull professional control system.
The front backgauge can be moved to clean the workplace.
Technical parameter:
Nominal capacity:400 KN
Length of working table:1500mm
Distance between uprights:1140mm
Throat depth: 350mm
Ram stroke:160mm
Max. Opening height:400mm
Main motor power:4KW
Oil tank capacity:160L
Dimension: 1700*1540*2350mm
Net weight:3800kg
| Tech Parameter Comparison Between SanXing 'Fully Servo' CNC Bending Machine and Normal CNC Bending Machine | ||||||||
| Comparative Model | SanXing Fully Servo Bending Machine | Normal CNC Bending Machine | ||||||
| Position Precision (Degree of accuracy) | <0.2mm | >0.4mm~1mm | ||||||
| Re-Position Precision (degree of accuracy) | <0.02mm | >0.2mm | ||||||
| Maintaining | Easy | Difficult | ||||||
| Requirements for Operator | Low | High | ||||||
| Oil Leaking | No | Yes | ||||||
| Durability of the Screw inside Hydraulic Cylinder | Durable | Break after 2 Yeas | ||||||
| Noise(Decibel) | 57 | 72 | ||||||
| Electricity Saving | 60% Saving | No Saving | ||||||
| Hydraulic Saving | 60% Saving | No Saving | ||||||
Photo comparison:
The reason why you choose our machine:
1. Electricity Saving :60%
2. Hydraulic saving:60%
3.Low noise
4.Save the cost of staff.Easy to operate.
5.High precision of re-position.
